Flame Proof Junction Box
Flame Proof Junction Box

Explosion Proof Junction Box Class 1 Div 2 Ex e Junction Box SJB-A-e Series

Advantages

Born for class 1 div 2 junction box, explosion proof junction box SJB-A-e series is protected by strictly sealed increased safety housing and terminal blocks and can be designed into CAD drawing by our engineer team subject to the class 1 div 2 distance requirement and project junction box arrangement before production, no matter how many feeders and how high the rated current is, our engineer can maximize the flexibility for internal space and future changes to be atex approved junction box.

Features
Selection Table
Data Sheet
Outline Dimensions

Features

Explosion Proof Junction Box SJB-A-e Series

01

High impact resistance aluminum alloy increased safety Ex e housing

Ex De Junction Box
02

Scientific rail mounted terminal blocks for concentrated all-in-one layout

Exd Junction Box

Selection Table

Explosion Proof Junction Box SJB-A-e Series

Explosion Proof Junction Box SJB-A-e Series

Data Sheet

Explosion Proof Junction Box SJB-A-e Series

CompliacesIEC Standard
IEC60079-0, IEC60079-7, IEC60079-11, IEC60079-31
Ex e IIC T6 Gb
Ex tb IIIC T80℃ Db IP66
Zone 1, Zone 2
Zone 21, Zone 22
EU Standard
EN60079-0, EN60079-7, EN60079-11, EN60079-31
ex-high-bay-lighting.jpgII 2 G Ex e IIC T6 Gb
ex-high-bay-lighting.jpgII 2 D Ex tb IIIC T80℃ Db IP66
Zone 1, Zone 2
Zone 21, Zone 22
NEC & CEC Standard
Class I, Div.1, Group A, B, C, D
Class II, Div.1, Group E, F, G
Class III
UL Standard
UL844, UL1598, UL1598A
CSA Standard
CSA C22.2 No.137
MaterialCopper-free aluminium,grey
Rated VoltageMax.690V AC
Rated CurrentMax.125A
IP GradeWet Locations, Type 4X, IP66
Ambient Temperature-50℃~ +55℃ /-58°F ~ +131°F
Cable EntryMetric or NPT thread type plugs (standard) or cable glands
Suitable Cable &
Rated Curent
2.5mm²4mm²6mm²10mm²16mm²35mm²
24A32A41A57A76A125A
TypeI / II / III / IV / V / VI / VII / VIII


Outline Dimensions

Explosion Proof Junction Box SJB-A-e Series

Outline Dimensions Of Explosion Proof Junction Box SJB-A-e Series

Type I

Outline Dimensions Of Explosion Proof Junction Box SJB-A-e Series

Type II

Outline Dimensions Of Explosion Proof Junction Box SJB-A-e Series

Type III

Outline Dimensions Of Explosion Proof Junction Box SJB-A-e Series

Type IV

Outline Dimensions Of Explosion Proof Junction Box SJB-A-e Series

Type V

Outline Dimensions Of Explosion Proof Junction Box SJB-A-e Series

Type VI

Outline Dimensions Of Explosion Proof Junction Box SJB-A-e Series

Type VII

Outline Dimensions Of Explosion Proof Junction Box SJB-A-e Series

Type VIII
