Explosion Proof Junction Box Flameproof Junction Box Exd SJB-IIC Series

Advantages

To fit in 1-way, 2-way, 3-way and 4-way threaded hubs arrangement, explosion proof junction box SJB-IIC series install terminal blocks in a rigid light-weight round box to protect the conductor in good manner and provide access for maintenance and future change of conduit layout. Different numbers of pipe blind plugs can be used for spare hubs with standard metric and NPT thread. You can use this explosion junction box, explosion proof conduit outlet box and dust proof electrical outlets in class 1 div 1, group A, B, C, D and zone 1, group IIC.

Features
Selection Table
Data Sheet
Outline Dimensions

Features

Explosion Proof Junction Box SJB-IIC Series

01

Excellent insulation material made inner terminal blocks to avoid the arcing

Class 1 Div 2 Junction Box
02

Various styles of outlets to thread with cable gland and conduit from four sides

Class 1 Div 1 Junction Box

Selection Table

Explosion Proof Junction Box SJB-IIC Series

Explosion Proof Junction Box SJB-IIC Series

Data Sheet

Explosion Proof Junction Box SJB-IIC Series

CompliacesIEC Standard
IEC60079-0, IEC60079-1, IEC60079-31
Ex d IIC T6 Gb
Ex tb IIIC T80℃ Db IP66
Zone 1, Zone 2
Zone 21, Zone 22
EU Standard
EN60079-0, EN60079-1, EN60079-31
ex-high-bay-lighting.jpgII 2 G Ex d IIC T6 Gb
ex-high-bay-lighting.jpgII 2 D Ex tb IIIC T80℃ Db IP66
Zone 1, Zone 2
Zone 21, Zone 22
NEC & CEC Standard
Class I, Div.1, Group A, B, C, D
Class II, Div.1, Group E, F, G
Class III
UL Standard
UL844, UL1598, UL1598A
CSA Standard
CSA C22.2 No.137
MaterialCopper-free aluminium,grey
Rated VoltageMax.500V AC
Rated Current16A / 25A
IP GradeWet Locations, Type 4X, IP66
Ambient Temperature-60℃~ +60℃ /-76°F ~ +140°F
Cable EntryMetric or NPT thread type plugs (standard) or cable glands
Terminal blocks6x(0.2~2.5)mm²
TypeI / II / III / IV / V / VI


Outline Dimensions

Explosion Proof Junction Box SJB-IIC Series

Outline Dimensions Of Explosion Proof Junction Box SJB-IIC Series

Outline Dimensions

Outline Dimensions Of Explosion Proof Junction Box SJB-IIC Series

Type I

Outline Dimensions Of Explosion Proof Junction Box SJB-IIC Series

Type II

Outline Dimensions Of Explosion Proof Junction Box SJB-IIC Series

Type III

Outline Dimensions Of Explosion Proof Junction Box SJB-IIC Series

Type IV

Outline Dimensions Of Explosion Proof Junction Box SJB-IIC Series

Type V

Outline Dimensions Of Explosion Proof Junction Box SJB-IIC Series

Type VI
