Explosion Proof Led Class 1 Div 1 Flashlight SPL-A Series

Name: Explosion Proof Led Class 1 Div 1 Flashlight SPL-A Series
Brand: SUREALL TECHNOLOGY LIMITED

Advantages

Class I, Division 1, Groups C, D

Ex tb IIIC T80℃ Db IP67

Class I, Division 2, Groups A, B, C, D

Zone 1, Zone 2

Class II, Division 1, Groups E, F, G

Zone 21, Zone 22

Class II, Division 2, Groups F, G

-40℃ ~ +55℃

Class III

Type 4X，IP67

Ex d ib IIC T6 Gb

LED 3W

Specification 

Classified as class 1 division 1 and class 1 division 2 flashlight, SPL-A series explosion proof flashlight features light-weight compact size to be a portable usage of explosion proof rechargeable torch. Built-in 3w led explosion lamp with high brightness make it to be a excellent explosion proof led flashlight. Hazard class division can be class 1 div 1, class 1 div 2, class 2 division 1 and class 2 division 2 as hazardous location light, lighting zone can be atex rating zone 1, zone 21.

 Features

Data Sheet

Features
Explosion Proof Flashlight SPL-A Series

One-button on and off for easy and fast lighting

3W led lamp for basic checking brightness for maintenance

Data Sheet
Explosion Proof Flashlight SPL-A Series

Compliance	IEC Standard IEC60079-0, IEC60079-1, IEC60079-11 Ex d ib IIC T6 Gb Ex tb IIIC T80℃ Db IP67 Zone 1, Zone 2 Zone 21, Zone 22
	EU Standard EN60079-0, EN60079-1, EN60079-11 II 2 G Ex d ib IIC T6 Gb II 2 D Ex tb IIIC T80℃ Db IP67 Zone 1, Zone 2 Zone 21, Zone 22
	NEC & CEC Standard Class I, Division 1, Groups C, D Class I, Division 2, Groups A, B, C, D Class II, Division 1, Groups E, F, G Class II, Division 2, Groups F, G Class III
	UL Standard UL844, UL1598, UL1598A
	CSA Standard CSA C22.2 No.137
Rated Voltage	DC 3.7V
Charging Voltage	100-240V AC,50/60Hz
Wattage(W)	3W
Battery Capacity	2400mAh
Working Time	8-12h
Function	Working Light / Intense Light / Signal Light
IP Grade	Wet Locations, Type 4X, IP67
Ambient Temperature	-40℃~ +55℃ /-40°F ~ +131°F
Size & Weight	φ31X135mm, 0.12Kg
