Explosion Proof Panel Class 1 Div 2 Miniature Circuit Breaker SPN-ed-S Series

Advantages

Stainless steel material explosion proof panel SPN-ed-S series are widely used to withstand high strength mechanical impact and resist high corrosive condition in explosive atmosphere. Installed with built-in flame proof Ex d circuit breaker in increased safety Ex e housing and operating handle on the housing cover, this explosion proof panelboards can be used as hazardous location panel and atex db whose hazard class division is class 1 div 2 group A, B, C, D and zone 1 group IIC.

Features
Selection Table
Data Sheet
Outline Dimensions

Features

Explosion Proof Panel SPN-ed-S Series

01

Increased safety Ex e stainless steel housing

Explosion Proof Electrical Panel
02

Flame proof Ex d electrical breakers, buttons and indicators

Explosion Proof Panelboard

Selection Table

Explosion Proof Panel SPN-ed-S Series

Explosion Proof Panel SPN-ed-S Series

Data Sheet

Explosion Proof Panel SPN-ed-S Series

CompliacesIEC Standard
IEC60079-0, IEC60079-1,IEC60079-31
Ex d e IIC T6 Gb
Ex tD A21 T80℃ IP66
Zone 1, Zone 2
Zone 21, Zone 22
EU Standard
EN60079-0, EN60079-1, EN60079-31
ex-high-bay-lighting.jpgII 2 G Ex d e IIC T6 Gb
ex-high-bay-lighting.jpgII 2 D Ex tb IIIC T80℃ Db IP66
Zone 1, Zone 2
Zone 21, Zone 22
NEC & CEC Standard
Class I, Div.1, Group A, B, C, D
Class II, Div.1, Group E, F, G
Class III
UL Standard
UL844, UL1598, UL1598A
CSA Standard
CSA C22.2 No.137
MaterialStainless Steel
Rated VoltageMax.100V AC
Rated CurrentMax.160A
IP GradeWet Locations, Type 4X, IP66
Ambient Temperature-60℃~ +60℃ /-76°F ~ +140°F
Cable EntryMetric or NPT thread type plugs (standard) or cable glands
Buite-in ComponentsMain Switch(MCB or MCCB),Branch Switch(MCB or MCCB),Indicator,Pushbutton,Terminal etc.


Outline Dimensions

Explosion Proof Panel SPN-ed-S Series

Outline Dimensions Of Explosion Proof Panel SPN-ed-S Series

Type I

Outline Dimensions Of Explosion Proof Panel SPN-ed-S Series

Type II

Outline Dimensions Of Explosion Proof Panel SPN-ed-S Series

Type III

Outline Dimensions Of Explosion Proof Panel SPN-ed-S Series

Type IV

Outline Dimensions Of Explosion Proof Panel SPN-ed-S Series

Type V

Outline Dimensions Of Explosion Proof Panel SPN-ed-S Series

Type VI

Outline Dimensions Of Explosion Proof Panel SPN-ed-S Series

Type VII
