Explosion Proof Connector Class 1 Div 2 Liquid Tight Connectors SL Series

Name: Explosion Proof Connector Class 1 Div 2 Liquid Tight Connectors SL Series
Brand: SUREALL TECHNOLOGY LIMITED

Advantages

Class I Division 2,Group A,B,C,D

Zone 1, Zone 2

Class II Division 1,Group E,F,G

Zone 21, Zone 22

Class III

Type 4X，IP66

Ex d II Gb

Max. NPT4"

Ex tb IIIC Db IP66

Advantages of Explosion Proof Connectors

Specification 

SL series explosion proof liquid-tight connector is designed to connect the liquid-tight flexible metal conduit to explosion proof lighting, explosion proof junction box, explosion proof panel and explosion proof enclosure in wet, dusty, corrosive and explosive environment. Depends on the installation areas, this explosion proof connector can be requested with straight type, 90°angle type and 45°angle type as class 1 div 2 liquid tight connectors to meet class 1 division 2 conduit requirements.

 Features

Selection Table

Data Sheet

Outline Dimensions

Features
Explosion Proof Connector SL Series

Cable conductor protection through the rubber ring

Quick connection to liquid tight conduit

Male flame proof thread for convenient connection to enclosure

Selection Table
Explosion Proof Connectors SL Series

Data Sheet
Explosion Proof Connector SL Series

Compliaces	IEC Standard IEC60079-0, IEC60079-7, IEC60079-31 Ex e II Gb Ex tb IIIC Db IP66 Zone 1, Zone 2 Zone 21, Zone 22
	EU Standard EN60079-0, EN60079-7, EN60079-31 II 2 G Ex e II Gb II 2 D Ex tb IIIC Db IP66 Zone 1, Zone 2 Zone 21, Zone 22
	NEC & CEC Standard Class I, Div.2, Group A, B, C, D Class II, Div.1, Group E, F, G Class III
	UL Standard UL844, UL1598, UL1598A
	CSA Standard CSA C22.2 No.137
Material	Malleable Iron / Zinc Die Cast
IP Grade	Wet Locations, Type 4X, IP66
Ambient Temperature	-5℃~ +100℃ / -40°F ~ +212°F
