Flame Proof Connectors

Explosion Proof Connector Elbows SE Series

Advantages

For narrow space, conduit corner where no enough space to reach to operate and conduit layout turning where direction change requests, SE series explosion proof connector can be used as explosion proof elbow to change the conduit direction to fit in explosion proof lighting, explosion proof enclosure, explosion proof panel and explosion proof junction box., this flame proof connector also could be used as 3 4 emt pull elbow and hazardous area plug where flammable gas and dust produce to meet class 1 division 1 conduit requirements and class 1 division 2 conduit requirements.

Features
Selection Table
Data Sheet
Outline Dimensions

Features

Explosion Proof Connector SE Series

01

90°type structure to change the conduit direction

Explosion Proof Electrical Connectors
02

45°type structure to bend the conduit conveniently

Explosion Proof Cable Connectors
03

M male thread/ M male thread, M male thread/ F female thread, F female thread/ F female thread

Explosion Proof Ethernet Connectors

Selection Table

Explosion Proof Connector SE Series

Explosion Proof Connectors SE Series

Data Sheet

Explosion Proof Connector SE Series

CompliacesIEC Standard
IEC60079-0, IEC60079-1, IEC60079-7, IEC60079-31
Ex d IIC Gb
Ex tb IIIC Db IP66
Zone 1, Zone 2
Zone 21, Zone 22
EU Standard
EN60079-0, EN60079-1, EN60079-7, EN60079-31
ex-high-bay-lighting.jpgII 2 G Ex d IIC Gb
ex-high-bay-lighting.jpgII 2 D Ex tb IIIC Db IP66
Zone 1, Zone 2
Zone 21, Zone 22
NEC & CEC Standard
Class I, Div.1, Group A, B, C, D
Class II, Div.1, Group E, F, G
Class III
UL Standard
UL844, UL1598, UL1598A
CSA Standard
CSA C22.2 No.137
MaterialNickel Plated Brass / 304 Stainless Steel / 316 Stainless Steel
IP GradeWet Locations, Type 4X, IP66
Ambient Temperature-40℃~ +100℃ / -40°F ~ +212°F


Outline Dimensions

Explosion Proof Connector SE Series

Outline Dimensions Of Explosion Proof Connectors SE Series

1.90°Male & Female Thread

Outline Dimensions Of Explosion Proof Connectors SE Series

2.90°Male & Male Thread

Outline Dimensions Of Explosion Proof Connectors SE Series

3.90°Female & Female Thread

Outline Dimensions Of Explosion Proof Connectors SE Series

4.45°Female & Female Thread
