Explosion Proof Enclosure Price
Explosion Proof Enclosure Price

Explosion Proof Enclosure Exd 11c Class 1 Div 1 Enclosure SEE-IIC Series

Advantages

Designed with longer and more complicated flame path through threaded and plane structure, SEE-IIC series explosion proof enclosure is an aluminum alloy FLP enclosure to tough the inner probable explosion and cut off the possibility of explosion for the outer environment. Via installing with explosion proof electrical components, this explosion proof enclosure can be used as class 1 div 1 junction box with terminal blocks and explosion panel with circuit breakers for gas group A, B, C, D and gas group IIC. Customized configuration handle operators, direction and numbers of cable entries and explosion proof cable glands.

Features
Selection Table
Data Sheet
Outline Dimensions

Features

Explosion Proof Enclosure SEE-IIC Series

01

Aluminum alloy spigot joint with long cylindrical joint and plane joint of flame proof path to meet IIC explosion proof standard

Explosion Proof Enclosure Design
02

Special Opening feet on cover for convenient opening with flat wrench to protect the flame proof path

Explosion Proof Enclosure Factory

Selection Table

Explosion Proof Enclosure SEE-IIC Series

Explosion Proof Enclosure SEE-IIC Series

Data Sheet

Explosion Proof Enclosure SEE-IIC Series

CompliacesIEC Standard
IEC60079-0, IEC60079-1, IEC60079-31
Ex d IIC T6 Gb
Ex tb IIIC Db IP66
Zone 1, Zone 2
Zone 21, Zone 22
EU Standard
EN60079-0, EN60079-1, EN60079-31
ex-high-bay-lighting.jpgII 2 G Ex d IIC Gb
ex-high-bay-lighting.jpgII 2 D Ex tb IIIC Db IP66
Zone 1, Zone 2
Zone 21, Zone 22
NEC & CEC Standard
Class I, Div.1, Group A, B, C, D
Class II, Div.1, Group E, F, G
Class III
UL Standard
UL844, UL1598, UL1598A
CSA Standard
CSA C22.2 No.137
MaterialCopper-free aluminium,grey
Rated CurrentMax.630A
IP GradeWet Locations, Type 4X, IP66
Ambient Temperature-40℃~ +55℃ /-40°F ~ +131°F
TypeI / II / III / IV / V / VI / VII / VIII


Outline Dimensions

Explosion Proof Enclosure SEE-IIC Series

Outline Dimensions Of Explosion Proof Enclosure SEE-IIC Series

Type I

Outline Dimensions Of Explosion Proof Enclosure SEE-IIC Series

Type II

Outline Dimensions Of Explosion Proof Enclosure SEE-IIC Series

Type III

Outline Dimensions Of Explosion Proof Enclosure SEE-IIC Series

Type IV

Outline Dimensions Of Explosion Proof Enclosure SEE-IIC Series

Type V

Outline Dimensions Of Explosion Proof Enclosure SEE-IIC Series

Type VI
