Explosion Proof Led Flood Light Class 1 Div 2 Zone 2 SHF-IIA Series


Based on feature class 1 div 2, SHF-IIA explosion proof led flood lights share around 70% market share in all requests for explosion flood lighting and 30% among all requests for explosion proof lighting since most applied lighting zone are class 1 div 2, not class 1 div 1 instead. Along with extra light-weight and proper cost-effective highlights, this model become the typical explosion proof led lights from hazardous location lighting in oil and gas lighting turn-key project including but not limited to paint booth lights, gas station lights.

Selection Table
Data Sheet


Explosion Proof Led Flood Light SHF-IIA Series


Adjustable mounting angle to fit in installation surface

Exterior Solar Flood Lights

Pendant pole hanging to increase the flexibility for special areas

External Flood Light

Arranged fins for exchanging from heat air to cool air

External Flood Lights

Increased safety housing enhancing the safety grade

External Floodlight


Explosion Proof Led Flood Lights SHF-IIA Series

01. Oil Refinery

Oil refinery is a petroleum plant to separate crude oil into different kinds of useful petroleum products, during the chemical separation process, explosive gas, liquid will leak from the valves, distillation tower, pipe lines so that refinery areas are the most recognized hazardous locations where requests the most tough safety requirements. SUREALL explosion proof led flood lights are designed with copper-free aluminum alloy housing with brilliant heat sink dissipation to used in high level hazardous locations, significantly up-grading the safety for all processes and lowering the hidden dangerous risks.

02. Marine Industry

The reliability and durability of electrical light fittings bring a decisive influence to ensure a maintained high safety grade when installed at harsh offshore location and on the open seas, for which SUREALL developed led flood light hazardous area with corrosive-resistant surface treatment protected against salt water spray, standing salt water, crude oil and other corrosive solvents. Long-life led lamp and driver, separately can work continuously within 8 years, reducing the maintenance labor and cost especially for floating, production, storage and offloading FPSO ship, LNG ship and other solvents or liquid ship.

03. Food and Beverage Facilities

Impeccable hygiene and reliable safety are both key requirements of the food and beverage industry, especially for food storage and production part where dust and mist may present in the air during the process. Aiming to catering to this requirement, SUREALL provide flood light explosion proof with dust-free housing and ip66 led floodlight with higher to IP67 ingress protection for wet and dusty environment, taking into account all the vital parameters to guarantee with effective solutions to resist the effects of moisture and corrosive cleaning agents.

04. Sport Stadiums

In general, sport stadiums are designed with larger areas when compared with ones ten years ago, accommodating more and more quantities of seats and playgrounds, hence, the applications of a huge quantity of traditional stadium lights use up a increasing power supply and bill. Tailored to meet market needs, SUREALL adopt the most advance led technology to develop high lumen efficiency outdoor stadium lights with features such as long life, energy-efficient, excellent color rendering index.

Selection Table

Explosion Proof Led Flood Light SHF-IIA Series

ModelLumensWattageLumens per WattEquivalent HID Luminaire

Selection Table of Explosion Proof Led Flood Light SHF-IIA Series

Data Sheet

Explosion Proof Flood Light SHF-IIA Series


IEC Standard
IEC60079-0, IEC60079-1, IEC60079-31, IEC60598-2-1

Ex ec IIC T6/T3 Gc

Ex tb IIIC T85℃/T103℃ Db IP66

Zone 2
Zone 21, Zone 22
EU Standard
IEC60079-0, IEC60079-1, EN60079-31, EN60598-2-1

Ex ec IIC T6/T3 Gc

Ex tb IIIC T85℃/T103℃ Db IP66

Zone 2
Zone 21, Zone 22
NEC & CEC Standard
Class I Division 2,Group A, B, C, D
Class II Division 1, Group E, F, G
Class II Division 2, Group F, G
Class III
UL Standard
UL844, UL1598, UL1598A
CSA Standard
CSA C22.2 No.137
Rated Voltage100-277V AC 50/60Hz
200-480V AC 50/60Hz
Color Temperature2900-5000K
IP GradeWet Locations, Type 4X, IP66
Ambient Temperature-40℃~ +55℃ /-40°F ~ +131°F
Cable EntryNPT 3/4” or M25X1.5 (adaptor for M20x1.5, NPT 1”, NPT1 1/2”)
TerminalsTerminal blocks ≤ 2.5mm², cable diameter 10-14mm
Mounting TypeBracket
Beam Angle120°  / 90° / 60° / 40°


Explosion Proof Flood Light SHF-IIA Series

Mounting of Explosion Proof Led Flood Light SHF-IIA Series


Mounting of Explosion Proof Led Flood Light SHF-IIA Series


Mounting of Explosion Proof Led Flood Light SHF-IIA Series


Mounting of Explosion Proof Led Flood Light SHF-IIA Series


Mounting of Explosion Proof Led Flood Light SHF-IIA Series

Ceiling Bracket

Mounting of Explosion Proof Led Flood Light SHF-IIA Series

Wall Bracket


Explosion Proof Flood Lights SHF-IIA Series

SUREALL provide 5 year's limited warranty or any other warranty period specified in the contract for the explosion proof led flood lights takes effect from the date of purchase.

The Warranty Terms:

> The ex proof led flood light manufacturer may repair the defective product or send substitute for replacement, when repairing do not work in special case, the manufacturer may replace the complete set of flood light explosion proof for free.
> Installation labor, electricity cost and other related cost will not be covered.

> The defect caused by inappropriate use under the installation instructions will not be covered, especially normal abrasion as well as failures which affect the value or use of the product insignificantly.
