Name: Explosion Proof Led Flood Light Class 1 Div 1 Zone 1 SHF-I Series
Brand: SUREALL TECHNOLOGY LIMITED

Explosion Proof Led Flood Light Class 1 Div 1 Zone 1 SHF-I Series

Advantages

Class I Division 1,Group A,B,C,D

Zone 1,Zone 2

Class II Division 1,Group E,F,G

Zone 21, Zone 22

Class III

-40℃ ~ +55℃

Ex d e IIC T6 Gb

Type 4X，IP66

Ex tb IIIC T80℃ Db IP66

LED 30W- 200W,120lm/W,3000K-5000K

With well-constructed aluminum housing, SHF-I series explosion proof led flood light, as a prevalent model of explosion proof led lights, are rigid demand for refinery lighting and paint booth lights to brighten the large space for hazardous lighting solutions. In order to serve lighting solutions for upstream oil and gas and downstream gas station lights, lighting zone are designed for class 1 div 1, class 1 div 2, class 2 division 1 and class 2 division 2, atex zone can be also zone 1 and zone 2 as atex led floodlight.

 Features

Selection Table

Data Sheet

Mounting

Features
Explosion Proof Flood Light SHF-I Series

Adjustable lighting angle to direct to any requested points

Wide-spread and large-area heat dissipation structure for stable working

Separate small lens for every led chips unit to reduce light waste

Isolated high intensive flame proof aluminum housing for led driver

Selection Table
Explosion Proof Flood Light SHF-I Series

Model	Lumens	Wattage	Lumens per Watt	Equivalent HID Luminaire
SHF-I-30W	3600	30W	120	70W
SHF-I-40W	4800	40W	120	100W
SHF-I-60W	7200	60W	120	150W
SHF-I-80W	9600	80W	120	175-250W
SHF-I-100W	12000	100W	120	320-400W
SHF-I-120W	14400	120W	120	400W
SHF-I-150W	18000	150W	120	400W-600W
SHF-I-200W	24000	200W	120	1000W
SHF-I-240W	28800	240W	120	-

Selection Table of Explosion Proof Led Flood Light SHF-I Series

Data Sheet
Explosion Proof Flood Light SHF-I Series

Compliance	IEC Standard IEC60079-0, IEC60079-1, IEC60079-31, IEC60598-2-1 Ex d e mb IIC T6 Gb Ex tb IIIC T80°C Db IP66 Zone 1, Zone 2 Zone 21, Zone 22
	EU Standard EN60079-0, EN60079-1, EN60079-31, EN60598-2-1 II 2 G Ex d e mb lIC T6 Gb II 2 D Ex tb IIIC T80℃ Db IP66 Zone 1, Zone 2 Zone 21, Zone 22
	NEC & CEC Standard Class I, Div 1, Group A, B, C, D Class II, Div.1, Group E, F, G Class III
	UL Standard UL844, UL1598, UL1598A
	CSA Standard CSA C22.2 No.137
Rated Voltage	100-277V AC 50/60Hz 200-480V AC 50/60Hz
Wattage(W)	30W	40W	60W	80W	100W	120W	150W	200W	240W
Lumens(LM)	3600	4800	7200	9600	12000	14400	18000	24000	28800
Color Temperature	5000K/4000K/3000K
IP Grade	Wet Locations, Type 4X, IP66
Ambient Temperature	-40℃~ +55℃ /-40°F ~ +131°F
Cable Entry	NPT 3/4" or M25X1.5 (adaptor for M20x1.5, NPT 1", NPT1 1/2")
Terminals	Terminal blocks ≤ 2.5mm², cable diameter 10-14mm
Mounting Type	Bracket (Possible wall, ceiling, and block mounting with adjustable angle)
Beam Angle	120° / 60° / 45° / 30°
